Smart Router

Banana Pi BPI-R3 Mini Router board with MediaTek MT7986(Filogic 830),support Wi-Fi 6, 2 2.5GbE network

  • MediaTek MT7986(Filogic 830) Quad core ARM Cortex A53+MT7531 chip design
  • Wifi 6 4x4 2.4G Wifi(MT7975N) +4x4 5G Wifi(MT7975P)
  • 2G DDR RAM
  • 8G eMMC flash
  • 2 2.5GbE network port
  • M.2 Key B interface
  • M.2 KEY M PCIe inerface
  • USB interfact
    Banana Pie BPI-R3 Mini router board development board using Mediatek MT7986A(Filogic 830) quad-core ARM A53 chip design, onboard 2G DDR memory, 8G eMMC and 128MB SPI NAND storage, is a very high performance open source router development board. It supports Wi-Fi6 2.4G/5G (MT7976C), two 2.5G network ports, NVME SSD(2230), 4G LTE, and 5G network expansion.

    • MediaTek MT7986(Filogic 830) Quad core ARM Cortex A53+MT7531 chip design
    • Wifi 6 4x4 2.4G Wifi(MT7975N) +4x4 5G Wifi(MT7975P)
    • 2G DDR RAM
    • 8G eMMC flash
    • 2 2.5GbE network port
    • M.2 Key B PCIe inerface
    • M.2 KEY M PCIe inerface
    • USB interfact

    Hardware interface:



    BPI-R3 Mini with Case:



    Online Wiki devlopment documents: https://wiki.banana-pi.org/Banana_Pi_BPI-R3_Mini
